LED Wattage and CCT Selectable Surface Mount Downlight

Surface-mounted fixture with a recessed-style design (5.5" size) for quick, tool-free installation. Compatible with most LED dimmers (10–100% smooth dimming, flicker- and noise-free). ENERGY STAR and ETL-certified for safety and efficiency. Features instant-on flicker-free LED technology for eye comfort and a sleek, canless profile ideal for modern spaces.

CertificationFeatureApplication
  • FEATURE AND BENEFIT
  • SPECIFICATION
  • DOCUMENTATION
  • Feature:

    - 120 V and 120-277 V, 60Hz available

    - PF ＞ 0.9

    - CRI ＞ 90

    - White tunable in 5 discrete color temperature 2700/3000/3500/4000/5000K, can be changed before, during or after installation

    - Lumen adjustable during 2-stage to meet the different environmental requirements

    - Ambient Temp: -20°C-40°C

    - Dimming: 0-10V


    Benefit:

    - Die cast aluminum housing routes heat away from electrical components

    - Precision engineered optical stack creates uniform light distribution that maximizes lumen output

    - High quality glass lens ,edge to edge, for every lit spaces

    - Smooth dimming feature and compatible with a wide variety of dimmers

    - Lumen adjustable during 2-stage to meet the different environmental requirements

    - Easy installation and maintenance

  • Watts11W
    MaterialPC
    Item NumberHT-G25LA-RD5-911-273-ZZ1
    Input Frequency120VAC, 60Hz
    Lumens700LM
    Efficacy(lm/w)64LM/W
    Life Span(Hr)5years
    DimmableY
